By R.A. Kishore Nadkarni, Steve Hepburn

Jul 26, 2016

New Proficiency Testing Programs for Petroleum Coke and Petroleum Naphtha

The ASTM International Proficiency Testing Programs include globally used petroleum-related quality management options; the two newest PTPs in this area, on petroleum coke and petroleum naphtha, are highlighted here.

Proficiency testing programs are widely used in various industries to assess laboratory capabilities for analyzing specific products by specific test methods. Participation in a PTP helps a laboratory compare its performance against that of other laboratories in the industry. It also helps standards developing organizations such as ASTM International establish the real-world performance of a test method and improve on it when possible.

PTP Logistics: Petroleum Coke and Petroleum Naphtha
	Petroleum Coke	Petroleum Naphtha
Frequency	Quarterly (January, April, July and October) Alternated between Green Coke and Calcined Coke	Three times per year(February, June and October)
Amount Provided	500 g	1 quart
Analysis Required	See "Standards in the Petroleum Coke PTP"	See "Standards in the Petroleum Naphtha PTP"
2013 Annual Registration Fee	$673.00	$486.00

Participation in a PTP should be a critical ingredient in any laboratory's quality management system; it will demonstrate proficiency to customers and help meet the accreditation requirements of bodies such as the American Association for Laboratory Accreditation, the American Petroleum Institute, the Chemical Manufacturers Association and others. For example, the CMA Product Approval Code of Practice requires participation in the ASTM International lubricating oil PTP, sponsored by Committee D02 on Petroleum Products and Lubricants, for laboratories submitting data for oil approvals to API.^1-3

ASTM International has taken the lead in sponsoring PTPs since the early 1990s. The first ASTM committee to launch a PTP was Committee D02. Since then, other ASTM committees have initiated similar PTPs in the areas of chemical analysis of metals, ores and related products; gold in bullion; plastics; textiles; and plain carbon and low alloy steels.

Committee D02's proficiency testing programs serve the global petroleum industry. The committee began sponsoring PTPs in 1993, covering four products and involving about 370 participating units (some laboratories participate in multiple programs). Since then, D02's PTP programs have grown to include 25 products and more than 3,289 participating units. Among the participating laboratories, about 57 percent are non-U.S. based laboratories.

PTP Participation Benefits

There are a number of benefits to participating in ASTM International proficiency testing programs. The programs provide an expedient way to assess the bias of one laboratory relative to others in the industry. Programs provide data for monitoring a laboratory's strengths and weaknesses across numerous test methods and products. Programs offer the ability to compare results among several test methods measuring the same parameters. Participation helps satisfy laboratory accreditation requirements. Satisfactory PTP performance can demonstrate testing capability to both internal and external customers of a laboratory. The program also helps ASTM committees validate test method performance under real-world conditions, and improve or modify method details where necessary, ultimately resulting in better precision and accuracy.

New D02 PTP Programs

This year, two new programs have been added to Committee D02's lineup of PTPs - petroleum coke and petroleum naphtha (see "PTP Logistics: Petroleum Coke and Petroleum Naphtha," below, for an overview).

Petroleum Coke

There are multiple kinds of petroleum coke, sometimes called sponge coke, shot coke, needle coke, fluid petroleum coke, etc.

Standards in the Petroleum Coke PTP

D1552, Test Method for Sulfur in Petroleum Products (High-Temperature Method)

D2638, Test Method for Real Density of Calcined Petroleum Coke by Helium Pycnometer

D4422, Test Method for Ash in Analysis of Petroleum Coke

D5056, Test Method for Trace Metals in Petroleum Coke by Atomic Absorption

D5600, Test Method for Trace Metals in Petroleum Coke by Inductively Coupled Plasma Atomic Emission Spectrometry (ICP-AES)

D6374, Test Method for Volatile Matter in Green Petroleum Coke Quartz Crucible Procedure

D6376, Test Method for Determination of Trace Metals in Petroleum Coke by Wavelength Dispersive X-Ray Fluorescence Spectroscopy

Since petroleum coke is a very heterogeneous material, sampling is a big problem in its analysis. The ASTM sampling standards are given for petroleum coke in D6969, Practice for Preparation of Calcined Petroleum Coke Samples for Analysis, and D6970, Practice for Collection of Calcined Petroleum Coke Samples for Analysis, and for coal coke, in D346/D346M, Practice for Collection and Preparation of Coke Samples for Laboratory Analysis. The standards all require starting with several tons of material to obtain an analytical sample. This is beyond the ability of the bottling and distribution facility at ASTM International's disposal so the bulk material suppliers pulverize and homogenize the sample and provide ASTM with a 60-mesh sample in sufficient quantities to cover each crosscheck. Two samples of calcined petroleum coke and two samples of green petroleum coke are distributed alternately each quarter to the laboratory participants. Approximately 500 g of test material is provided to each participant in each test cycle.

Data obtained from calcined petroleum coke samples are used in commercial transactions, controlling plant operations and allocating production costs. The ash content is used to evaluate petroleum coke and indicates the undesirable residue present. Acceptable ash content varies with the intended use of the coke. The real density of calcined petroleum coke directly influences the physical and chemical properties of the manufactured carbon and graphite artifacts for which it is needed.

Real density, therefore, is a major quality specification of calcined petroleum coke and is used as a control in coke calcination. The volatile matter of petroleum coke affects the density of coke particles and can affect artifacts produced from further processing of the coke. It can also be used in estimating the calorific value of coke. The presence and concentration of sulfur and various metallic elements in petroleum coke are major factors determining the suitability of a coke for various purposes. Sulfur content can be used to evaluate the potential formation of sulfur oxides, a source of atmospheric pollution.

There are a large number of test methods for characterizing petroleum coke for the above analyses. The tests chosen for inclusion in the PTP program for petroleum coke (see box, "Standards in the Petroleum Coke PTP") were based on the availability of published precision estimates in the ASTM standards, their applicability to green or calcined coke, and which did not require extremely large quantities of samples for analyses.

Petroleum Naphtha

The latest addition to ASTM Committee D02's PTP program is one for petroleum naphtha. It is scheduled to be conducted three times per year, in February, June and October. Approximately one quart of the commercial grade material is distributed to each laboratory participant. A large number of tests were originally offered, but only a limited number seemed to be of interest to the laboratories based on data return. The relevant tests are listed in the box, "Standards in the Petroleum Naphtha PTP." A dramatic difference between the compositions of the two naphtha samples was found in the results because there is no ASTM specification requirement for naphtha. It is traded as a commodity and the manufacturer provides its composition to the customer. As a result, the amount can vary among manufacturers.

Standards in the Petroleum Naphtha PTP1

D86, Test Method for Distillation of Petroleum Products at Atmospheric Pressure

D130, Test Method for Corrosiveness to Copper from Petroleum Products by Copper Strip Test

D1319, Test Method for Hydrocarbon Types in Liquid Petroleum Products by Fluorescent Indicator Adsorption

D2622, Test Method for Sulfur in Petroleum Products by Wavelength Dispersive X-Ray Fluorescence Spectrometry

D2887, Test Method for Boiling Range Distribution of Petroleum Fractions by Gas Chromatography

D3227, Test Method for (Thiol Mercaptan) Sulfur in Gasoline, Kerosine, Aviation Turbine and Distillate Fuels (Potentiometric Method)

D4052, Test Method for Density, Relative Density and API Gravity of Liquids by Digital Density Meter

D4294, Test Method for Sulfur in Petroleum and Petroleum Products by Energy Dispersive X-Ray Fluorescence Spectrometry

D4629, Test Method for Trace Nitrogen in Liquid Petroleum Hydrocarbons by Syringe/Inlet Oxidative Combustion and Chemiluminescence Detection

D5134, Test Method for Detailed Analysis of Petroleum Naphthas Through n-Nonane by Capillary Gas Chromatography

D5191, Test Method for Vapor Pressure of Petroleum Products (Mini Method)

D5443, Test Method for Paraffin, Naphthene and Aromatic Hydrocarbon Type Analysis in Petroleum Distillates Through 200°C by Multi-Dimensional Gas Chromatography

D5453, Test Method for Determination of Total Sulfur in Light Hydrocarbons, Spark Ignition Engine Fuel, Diesel Engine Fuel and Engine Oil by Ultraviolet Fluorescence

D5599, Test Method for Determination of Oxygenates in Gasoline by Gas Chromatography and Oxygen Selective Flame Ionization Detection

D6045, Test Method for Color of Petroleum Products by the Automatic Tristimulus Method

D6839, Test Method for Hydrocarbon Types, Oxygenated Compounds and Benzene in Spark Ignition Engine Fuels by Gas Chromatography

D7039, Test Method for Sulfur in Gasoline and Diesel Fuel by Monochromatic Wavelength Dispersive X-Ray Fluorescence Spectrometry

D7423, Test Method for Determination of Oxygenates in C2, C3, C4 and C5 Hydrocarbon Matrices by Gas Chromatography and Flame Ionization Detection

For More Information

Laboratories are welcome to participate in and learn more about all PTP programs for fuels, lubricants, textiles, plastics and metals testing either online or by contacting Steve Hepburn (phone: 610-832-9688).

References

1. Nadkarni, R.A., "Does Your Laboratory Measure Up? ASTM Program Helps Build Proficiency," Lubes'N'Greases, Vol. 7, No. 4, April 2001, pp. 28-34.

2. Bover, W.J., "Tackling Interlaboratory Variability for the Global Marketplace: Committee D02's Cross Check Program," ASTM Standardization News, Vol. 22, No. 6, June 1994, pp. 56-63.

3. Bover, W.J., Jones, J.T., Renz, M.C., and Nadkarni, R.A., "ASTM, the Petroleum Industry, and Quality Assurance," ASTM Standardization News, Vol. 26, No. 4, April 1998, pp. 29-32.

R.A. Kishore Nadkarni, Ph.D., president of Millenium Analytics, East Brunswick, N.J., has been an ASTM International member since 1983. He works on several groups in ASTM Committee D02 on Petroleum Products and Lubricants, where he also serves as a section and subcommittee chairman. Author of more than 100 technical publications in the area of analytical chemistry and quality management, Nadkarni is also a member of the American Chemical Society. An ASTM Award of Merit recipient, Nadkarni has received the D02 Award of Appreciation, four D02 Awards of Excellence, the George V. Dyroff Award of Honorary Committee D02 Membership and the Sydney D. Andrews Scroll of Achievement.

Steve Hepburn is director of proficiency testing programs and contract/project management services in the Certification, Training and Proficiency Testing division of ASTM International.
